Model | GSL 12V-80AH | GSL 12V-100AH | GSL 12V-120AH |
Products type | |||
Cell Technology | LiFePO4 | ||
Battery Pack Capacity (Wh) | 1024 | 1280 | 1536 |
Battery pack Voltage (Vdc) | 12.8 | ||
Battery pack Capacity (AH) | 80 | 100 | 120 |
Battery pack Cell Quantity in Series (pcs) | 4S | ||
Battery pack Charge Voltage (Vdc) | 14.6 | ||
Battery System Charge Current (Standard) | 10A | ||
Battery pack Charge Current (Normal) | 20A | ||
Battery pack Charge Current (Max.) | 50A | ||
Battery pack Discharge lower-Voltage (Vdc) | 10V | ||
Battery System Discharge Current (Standard) | 20A | ||
Battery pack Discharge Current (Normal) | 80A | 100A | |
Battery pack Discharge Current (Max.) | 250A | 250A | |
Efficiency | 98% | ||
Depth of Discharge | 100% | ||
Communication | Option of CANBUS OR RS485, SMbus | ||
Protection Class | IP54 | ||
Operation Life | 10+ years | ||
Operation Cycle Life | Over 4000 times | ||
Operation Temperature | 0-50℃ | ||
Storage Temperature | minus 20 -- 60 ℃ | ||
Dimension (L*W*H, mm) | 323*171*215 | ||
Weight | 10.5kg | 12.8kg | 14.5kg |
