|Products type||MODEL : KS1240||Battery pack Discharge Current (Max.)||80A|
|Battery Pack Capacity (Wh)||512||Depth of Discharge||100%|
|Battery pack Voltage (Vdc)||12.8||Dimension (L*W*H, mm)||197*165*169|
|Battery pack Capacity (AH)||40||Communication||Option of CANBUS OR RS485, SMbus|
|Battery pack Cell Quantity in Series (pcs)||4S||Protection Class||IP54|
|Battery pack Charge Voltage (Vdc)||14.6||Weight||4.5KG|
|Battery System Charge Current (Standard)||10A||Operation Life||10+ years|
|Battery pack Charge Current (Normal)||20A||Operation Cycle Life||Over 4000 times|
|Battery pack Charge Current (Max.)||40A||Operation Temperature||0-50℃|
|Battery pack Discharge lower-Voltage (Vdc)||10V||Storage Temperature||minus 20 -- 60 ℃|
|Battery System Discharge Current (Standard)||20A||Products certificates||TÜV (IEC62619), CE|
|Battery pack Discharge Current (Normal)||40A||Transfer Certificates||UN38.3 , MSDS|
12V lithium ion battery is new environmentally friendly backup power system focus on short-time and high-rate discharge scenarios.The environmentally friendly lithium ion battery configured with high-performance BMS, has a wide range of performance and application advantages compared with conventional battery.
1.High integrated with less installation space.
2.Long life cycle, >3000 times at 80% DOD.
3.Without heavy metals and environment friendly.
4.Maintenance free, no memory effect.
5.Internal BMS with full protection, high voltage protection with higher reliability.
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
--Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
--RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
--LED Backup / Engine Starting Battery,etc.
SUPER SAFETY TEST
Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.
WHY CHOOSE US
◆ Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
◆ Fresh battery-- All battery is fresh Production.
