PRODUCT ADVANTAGE
Basic System Architecture
The following illustration shows basic application of this inverter.
It also includes following devices to have a Complete running system.
- Generator or Utility
- PV modules
Consult with your system integrator for other possible system architectures depending on your requirements.
This inverter can power all kinds of appliances in home or office environment, including motor type appliances such as refrigerator and air conditioner.
Model | GSL-H-8KLV-US |
PV Input | |
PV Input Power | 12KW |
MPPT Number | 4 |
PV Voltage Range | 350V/85V-500V |
MPPT Voltage Range | 120V-500V |
Single MPPT Input Current | 12A |
Battery | |
Max Charging/Discharging Current | 190A/190A |
Battery Voltage Range | 48V |
Battery Type | Lithium-ion,Lead-acid |
Back-up AC Output | |
Rated Backup Output Power | 8KVA |
Max Backup Output Power | 10KVA 60S,12KVA 1S |
Backup AC Output Voltage | 120Vac/240Vac (Split phase),208Vac (2/3 phase) ,230Vac (Single phase) |
AC Frequency | 50/60Hz |
Output THDI | <2% |
On Grid AC Output | |
Rate AC Output Power | 8KVA |
AC Output Voltage | 120Vac/240Vac (Split phase),208Vac (2/3 phase) ,230Vac (Single phase) |
AC Output Frequency | 50/60Hz |
Grid Type | Split phase, 2/3 phase, Single phase |
Max Output Current | 38.3A |
AC Reverse Charging | Yes |
PF | 0.8leading...0.8lagging |
Output THDI | <2% |
Efficiency | |
Max Eifficiency | >=98.2% |
CEC Eifficiency | >=97.2% |
General Data | |
Operating Temperature Range | -25~+60℃ |
Environment Humidity | 0-95% |
Altitude | 0-4000M (over 2000M derating) |
IP Rank | IP65/NEMA 3R |
Cooling | Fan |
Noise (dB) | <29dB |
Communication | Modbus;RS485;WIFI;4G |
Weight (kg) | 45KG |
Size (Length*Width*Height mm) | 430×710×210mm |
Display | LCD |
Safty | EN61000-6-1,EN61000-6-3,FCC 15 clase B |
EMC | IEC62109-1,IEC62109-2 |
On Grid | UL1741,IEEE1547,RULE21,VDE0126,AS4777,NRS2017,G98,G99 |
Application Scenario
APPLICATION
WHY CHOOSE US
◆ Experience--More than 15 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification--CE/ROSH/UL/VDE/MSDS/UN38.3,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
◆ Fresh battery-- All battery is fresh Production.
