10kWh/14.34kWh/16.38kWh 200Ah/280Ah/320Ah 51.2V IP65 Waterproof Solar Lithium-ion Battery
GSL Power storage wall is a battery that stores energy, detects outages and automatically becomes your home's energy source when the grid goes down. Your system detects outages, powers your home and electric vehicle with backup energy and automatically recharges with sunlight to keep your appliances running for days.
Pair with solar and recharge with sunlight to keep your appliances running for days. Power storage wall reduces your reliance on the grid by storing your solar energy for use when the sun isn't shining.
Use Power storage wall alone or combine it with other GSL products to save money, reduce your carbon footprint and prepare your home for power outages.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
| MODEL NO | GSL051200A-B-GBP2 | GSL051280A-B-GBP2 | GSL051320A-B-GBP2 | |
| Battery Chemistry | LiFePO4 | |||
Capacity (Ah) | 200 | 280 | 320 | |
| Scalability | Max.16pcs in parallel (162kWh) | Max.16pcs in parallel (229kWh) | Max.16pcs in parallel (262kWh) | |
Nominal Voltage (V) | 51.2 | |||
| Operating Voltage (V) | 46-56 | |||
Energy (kWh) | 10.24 | 14.34 | 16.38 | |
Usable Energy (kWh) | 9.22 | 12.91 | 13.10 | |
Charge/Discharge Current (A) | Recommend | 100 | ||
Max. | 150 | |||
Peak(2mins,25℃) | 200 | |||
| Other Parameter | ||||
| Recommend Depth of Discharge | 80% | |||
| Dimension (W/H/D,mm) | 550*800*160 | 900*675*200 | 900*675*200 | |
Weight Approximate (kg) | 102.50 | 128.50 | 146.50 | |
| Master LED Indicator | 4 LED (SOC:25%~100%) | |||
| 2 LED (working, alarming, protecting) | ||||
IP Rating of Enclosur | IP65 | |||
| Working Temperature | Charge:0℃～55℃ Discharge:-20℃～55℃ | |||
Storage Temperature | 0℃～35℃ | |||
| Humidity | 5%~95% | |||
| Altitude | ≤2000m | |||
| Cycle Life (25±2℃,0.5C/0.5C,80%EOL) | ≥6500 | ≥8500 | ||
| Installation | Wallmounted | |||
| Communication Port | CAN2.0, RS485 | |||
| Warranty Period | 10 years | |||
| Certification | IEC-62619, CE-EMC, MSDS, UN38.3 | UL9540A, UL9540, UL1973, IEC-62619, CE-EMC, MSDS, UN38.3 | IEC-62619, CE-EMC, MSDS, UN38.3 | |
